Using a steam cleaner to inject steam

francoispied's picture
francoispied

Using a steam cleaner to inject steam

I am looking for an easy and safe(-ish) way to modify my Baker's Pride P44S pizza oven in order to introduce steam in a controlled way.



I know some people use modified pressure cookers, but that seems a little dodgy to me, so I'm wondering if anyone ever tried integrating one of those pressured steam cleaner instead?





alfanso's picture
alfanso

http://www.breadcetera.com/wp-content/uploads/2008/08/ScoringSteaming.mov

He drilled a hole in a hotel pan to do this.  He was fairly obsessive about technique.

tschaefges's picture
tschaefges

That's the same method I use: an inverted hotel pan and a Bissell Steam Shot. Works great. Although I have never tried it, the Steam Shot could probably be used to put steam directly in an oven. My oven is too well vented for that.

jo_en's picture
jo_en

Thanks for this link. I had only been spraying into the whole oven.

It’s a definite improvement!

Jimatthelake's picture
Jimatthelake

I seriously doubt that the steamer you're considering will provide enough steam on demand to steam your ovens.  I also question whether it can actually force the steam into an oven.  Seems to me, soneone else here tried it in the past, and it was a complete fail.

I've modified my Bakers Pride P24S Hearth series oven so I can inject steam into it.  As you probably know, I use a Presto 6 qt electric pressure cooker to generate the steam.  I've plumbed it up with a ball valve, and 1/4" silicone steam tubing.  The pressure cooker is 120v, rated at 1410w, and has a temp control.  Even when I adjust the temp control to max 400 degrees,  when I open the ball valve, the pressure cooker can't keep up with the steam flowing into the oven.  If I open the valve half way, the cooker can keep up, and provide continious steam until the cooker runs out of water.

I've taken to steaming my current rustic pan formed loaves for 8 minutes, and when I measure the water used by the pressure cooker, at half open, it uses about 500 ml.  My oven is about half the size of yours.  Do you plan to use both your units at the same time?  Do you plan to use both decks in both ovens?  If so, I don't think even my pressure cooker could not provide enough steam for both units.

My oven has only one deck.  I think both of yours have two decks.  Since the actual oven "box" for my oven is also used for models with two decks, there are 2 holes in the middle of the back to accomodate the third element.  It was simple for me to pop out the plug on one of these holes to insert my steam injection fitting.  The pressure cooker sits on top of the oven and plugs into an adjacent 120v outlet.  Simple and clean.

I'm really quite pleased with my set up.  I don't have photos to show, but if I can be of any further help let me know.  Jim

PS  After again reading your question, I think you're looking for a real steam generator.  The unit you reference won't do the job.  If a pressure cooker is to "doggy", I sugest you look for a steam generator that can turn at least 1 gal of water per hour to steam.  I think they're popular for things like steam showers
